  • SJ-Y2顆粒自動包裝機

  • SJ-Y2顆粒自動包裝機
  • 【SJ-Y2顆粒自動包裝機】詳細信息



  • 特點 Features

    背封,三邊封,四邊封包裝形式

    包裝運行數據及調節在顯示屏上直觀顯示,直接操作

    裝配光電控制裝置保證包裝袋圖案完整

    自動完成制袋,計量,充填,封合,斷切,計數,打印批號

    殼體及物料接觸部位使用不銹鋼材料
    Back sealing, three-side sealing, four-side packing method
    The packing running data and adjustment are directly displayed on the display. The user can directly operate it on the displayer.
    Equipped with a photoelectric controller to ensure that its packing bag patterns are perfect.
    It can automatically finish making-bag, metering, filling, sealing, cutting, counting
    and printing batch number.
    The body and the parts touching the material are made of stainless steel.

    適合物料 Suitable material

    食品,醫藥,化工,種子,日化行業松散狀無粘性顆粒物料
    It is applicable for packing foodstuff, medicine, chemical industry, seed, and the loosing
    non-sticking granule daily chemical industry.

    技術規格 Technical specifications
    型號

    Type

    SJ-Y2

    SJ-Y300
    制成袋長 mm

    bag-making length

    50-170

    50-280

    制成袋寬 mm

    Bag-making width

    25-120

    70-190
    包裝薄膜寬度 mm Packing film width 60-240 160-380
    包裝容量 ml

    Packing capacity

    5-100

    50-1400

    包裝速度 bags/min

    Packing speed

    35-70

    20-40

    功率 Kw power

    1.6

    1.65

    氣源 Mpa

    air power

    0.6

    0.65
    耗氣量 L/min

    air consumption

    100 100
    外形尺寸 mm

    Overall Dimension

    760×980×1800

    900×1120×2360
    整機質量 Kg

    Weight

    300 480
